The ZigBee Wireless Dimmer Switch is a Zigbee 3.0-based dimmer switch designed for controlling universal single color Zigbee lighting devices, supporting touchlink commissioning without a coordinator and find and bind mode for pairing within the same network. It allows binding of one group with up to 30 devices, operates on the 2.4 GHz global frequency band, offers a transmission range of up to 30 meters, and features long battery life mesh technology, making it compatible with universal Zigbee Gateway products.
| Protocol | ZigBee 3.0 |
|---|---|
| Operation Voltage | 3VDC (CR2032) |
| Transmission Frequency | 2.4GHz |
| Transmission Range (free field) | 30m |
| Protection Type | IP20 |
| Dimming Range | 0.1%-100% |
| Dimensions | 80x80x10.5mm |
