The ZigBee Wireless Dimmer Switch is a Zigbee 3.0-based device that enables pairing with Zigbee lighting devices via touchlink commissioning without a coordinator, supports find and bind mode within the same network, allows control of up to 3 groups with a maximum of 30 lighting devices, operates on the 2.4 GHz global frequency, features long battery life mesh technology with a transmission range of up to 30 meters, and is compatible with universal Zigbee gateways and single color Zigbee lighting devices.
| Protocol | ZigBee 3.0 |
|---|---|
| Operation Voltage | 3VDC (CR2032) |
| Transmission Frequency | 2.4GHz |
| Transmission Range (free field) | 30m |
| Protection Type | IP20 |
| Dimming Range | 0.1%-100% |
| Dimension | 150×38.6x12mm |
| Protection Grade | IP20 |
