RGB CCT DIM 3 in 1 Zigbee Remote Controller

SR-ZG2801K4-5C

Product description

Zigbee RGB+CCT+DIM remote based on Zigbee 3.0
Enables to control both RGB and CCT lighting devices
Battery powered remote with low power consumption
Enables to pair Zigbee lighting devices via touchlink commissioning without coordinator
Supports find and bind mode to pair with Zigbee lighting devices
Supports 1 group for binding max. 30 lighting devices
2.4 GHz global operation
Transmission range up to 30m
Compatible with universal Zigbee Gateway products
Enables to bind and control universal DIM, CCT, RGB, RGBW and RGB+CCT Zigbee lighting devices

SR-ZG2801K4-5C is a RGB＋CCT＋DIM ZigBee remote control that enables switch and dimming control and works with a ZigBee gateway/coordinator, it shall join ZigBee network and bind compatible ZigBee lighting devices from ZigBee controller or hub interface so that it can control the devices. The ZigBee remote can be compatible with universal ZigBee gateway/coordinator and lighting devices thanks to interoperability of products with the same ZigBee Wireless standard.

Protocol	ZigBee 3.0
Input Voltage	3VDC (CR2430)
Transmission Frequency	2.4GHz
Transmission Range (free field)	30m
Protection Type	IP20
Dimming Range	0.1%-100%
Dimensions	86x86x14mm/80.5×80.5×14.7mm
