The DALI Single Color Touch Controller features a touch-sensitive glass interface available in white and black, and complies with DALI standard protocols IEC 62386-102 and IEC 62386-207, ensuring compatibility with other international DALI products.
It includes a built-in 100mA DALI power supply that can power up to 50 DALI ECGs, and is powered by the DALI bus when not connected to AC mains. The controller can manage up to 100 DALI ECGs on a DALI line through four control panels, with two powered by AC mains and two by the DALI bus.
It allows control of four DALI groups and three DALI scenes, with the ability to set the start DALI group number (0-15) and scene number (0-15) using rotary switches on the back. It also supports DT6 devices.
| Power supply | 100-240VAC/DALI bus |
|---|---|
| Output | DALI signal |
| Operation current | <15 mA |
| DALI bus output | 100 mA max |
| DALI consumption | 4 mA |
| Operating temperature | 0-40℃ |
| Relative humidity | 8% to 80% |
| Dimensions | 75x120x 41.6mm |
| Waterproof grade | IP20 |
