The Ultra-Pro 4CH RDM DMX512 Decoder is a DMX512 RDM decoder that enables communication between the DMX master and the decoder. It features a digital display for directly showing and easily setting the DMX address. With four PWM output channels, the device supports common anode configuration, and the DMX channel quantity can be set from 1CH to 4CH. The PWM output resolution is adjustable between 8bit and 16bit, and the output PWM frequency can be set from 500Hz to 30kHz. The output dimming curve gamma value is also configurable, ranging from 0.1 to 9.9, with the decoding mode being settable for various control needs.
| No. | 1 | 2 | 3 |
|---|---|---|---|
| Voltage Input | 12-36VDC | 12-48VDC | 12-48VDC |
| Output Current | 4x5A | 4x350mA | 4x700mA |
| Output Power | 4x(60-180)W | 4x(4.2-16.8)W | 4x(8.4-33.6)W |
| Remarks | Constant voltage | Constant current | Constant current |
| Size(LxWxH) | 170×53.4x28mm | 170×53.4x28mm | 170×53.4x28mm |
