The Matter + Zigbee to DALI DT8 CCT+0/1-10V 2 in 1 Converter is designed to convert Matter signals to DALI DT8 CCT and 0/1-10V control signals, with a 110-240VAC power input. It features a relay output with a maximum of 5A for incandescent and HV halogen lamps and 1.6A for LED loads. Compatible with universal Matter over Thread platforms, this device allows for the selection of either DALI or 1-10V output through a DIP switch. It includes a built-in DALI bus power supply, eliminating the need for an external DALI bus PS, and provides up to 50mA of DALI bus power to control up to 25 DALI control gears. The device offers color control based on DALI Device Type 8 specifications, with address or group control modes that can be adjusted via DIP switches. Users can select a specific DALI address (00-63) or group (0-15), control individual devices, groups, or all devices on the DALI line through broadcast. The converter supports app control via Matter (such as Apple Home, Amazon Alexa, and Google Home), touchlink remote control, and green power kinetic switch control.
| Input | Power | 110-240VAC |
|---|---|---|
| Input | Signal | Matter |
| Output, DALI | DALI PS current | Max. 50mA |
| Output, DALI | DALI current consumption | Max. 4mA |
| Output, 0/1-10V | Current | Max. 20mA |
| Output,relay | Switching voltage | 110-240VAC |
| Output,relay | Max. Current | Incandescent:5A LED: 1.6A |
| Environment | Operating temperature | －20℃~+50℃ |
| Environment | Relative humidity | 8% to 80% |
| Others | Dimensions | 95x37x20mm |
