The DMX2CC Dimmer 4CH operates in both DMX decoder and master modes with RDM functionality, featuring a digital display for direct data viewing and easy DMX address configuration. It provides four common anode constant current output channels with selectable DMX channel modes from 1CH to 4CH, and the output current can be adjusted from 100mA to 700mA via buttons, digital display, or RDM. The gamma dimming curve is configurable from 0.1 to 9.9, and the DMX personality and startup behavior can be set through RDM. The DMX signal input and output are electrically isolated with built-in anti-surge protection.
| Input Voltage | 12-48VDC |
|---|---|
| Output Current | 100-700mA selectable with 10mA increment |
| Output Voltage | 3-12V @ 12V input, 3-24V @ 24V input, 3-36V @ 36V input, 3-48V @ 48V input |
| Output Power | 4x(1.2-33.6)W @700mA |
| Remarks | Constant Current |
| Size(LxWxH) | 170×53.4x28mm |
