The DALI DT8 LED driver is a super-slim, highly efficient solution designed specifically for magnet track lighting and linear lighting applications. With a magnetic absorption installation method, it ensures seamless integration and eliminates high-frequency interference sounds. This controller operates with a DC48V input and provides a maximum output power of 28W, featuring two channels with a constant current output range of 100-700mA. The current is easily adjustable via dipswitches for multi-operation settings. It supports deep and smooth dimming down to 0.1%, offering flicker-free performance. Compliant with IEC 62386-101:2014, IEC 62386-102:2014, and IEC 62386-209 standards, the device integrates effortlessly with all DALI systems in the market. It also features a built-in DALI-2 interface for enhanced functionality. Designed with a waterproof rating of IP20, this LED controller is ideal for a variety of lighting environments and comes with a 5-year warranty for reliable performance. With an input voltage of 48VDC±5% (polarity-free) and an input current of 0.65A at full load, it delivers exceptional power efficiency and versatility.
| Output | LED Channel | 2 | ||||||
|---|---|---|---|---|---|---|---|---|
| Output | Selectable Current | 100mA | 150mA | 200mA | 250mA | 300mA | 350mA | 400mA |
| Output | DC Voltage Range | 24-40V | 24-40V | 24-40V | 24-40V | 24-40V | 24-40V | 24-40V |
| Output | Selectable Current | 450mA | 500mA | 550mA | 600mA | 650mA | 700mA | |
| Output | DC Voltage Range | 24-40V | 24-40V | 24-40V | 24-40V | 24-40V | 24-40V | |
| Output | Rated Power | Max. 28W | ||||||
| Input | Dimming Interface | DALI-2 (DALI consumption < 2mA) | ||||||
| Input | Voltage | 48VDC±5% (Polarity Free) | ||||||
| Input | Current | 0.65A @ full load | ||||||
| Input | Efficiency | 95% | ||||||
| Input | Standby Power | <0.5W | ||||||
| Protection | Over Load | Yes. Remove the fault conditions and re-power the device. | ||||||
| Protection | Non-load | Yes. Remove the fault conditions and re-power the device. | ||||||
| Protection | Short Circuit | Yes. Remove the fault conditions and re-power the device. | ||||||
| Protection | Anti-reverse | Prevent driver and load damage | ||||||
| Environment | Working Temp. | -20°C~+45℃ | ||||||
| Environment | Working Humidity | 10% ~ 95% RH non-condensing | ||||||
| Environment | Storage Temp. & Humidity | -40°C~+80°C,10%~95%RH | ||||||
| Others | Dimension | 125*14*10mm(L*W*H) |
