4-key Single Color Wall Mounted ZigBee Keypad

SR-ZG9001NK4-DIM

Product description

Zigbee dim remote based on Zigbee 3.0
Enables to control single color lighting devices
Battery powered remote with low power consumption
Enables to pair Zigbee lighting devices via touchlink commissioning without coordinator
Supports find and bind mode to pair with Zigbee lighting devices
Supports 2 groups for binding max. 30 lighting devices
2.4 GHz global operation
Transmission range up to 30m
Compatible with universal Zigbee Gateway products
Compatible with universal single color Zigbee lighting devices
Front plate can be replaced with 8-key or 2-key front plate

SR-ZG9001NK4-DIM is a single color ZigBee remote control that enables switch and dimming control and works with a ZigBee gateway/coordinator, it shall join ZigBee network and bind compatible ZigBee lighting devices from ZigBee controller or hub interface so that it can control the devices. The ZigBee remote can be compatible with universal ZigBee gateway/coordinator and lighting devices thanks to interoperability of products with the same ZigBee Wireless standard.

Operation Frequency	2.4GHz
Transmission Range (free field)	30m
Power Supply	3VDC (CR2450)
Operating temperature	0-40℃
Relative humidity	8% to 80%
Dimming Range	0.1%-100%
Dimensions	86.0×86.0x15.2mm
Protection Type	IP20
