2-Key Zigbee Push Button Smart Switch

SR-ZG2835KAC-NK2-SW

Product description

ZigBee push button AC switch based on latest ZigBee 3.0 protocol
100-240VAC wide input and output voltage, can work under no neutral wiring and with neutral wiring, self-adaptive
Supports resistive loads, capacitive loads or inductive loads
1 channel output, max. load 10A
Enables to control ON/OFF of connected light source
Supports energy metering, real time energy consumption can be monitored
ZigBee device that supports Touchlink commissioning
Can be controlled by zigbee gateway, zigbee remote and local push buttons
Can directly pair to a compatible ZigBee remote via Touchlink without coordinator
Supports self-forming zigbee network without coordinator and add other devices to the network
Supports find and bind mode to bind a ZigBee remote
Supports zigbee green power and can bind max. 20 zigbee green power remotes
Compatible with universal ZigBee gateway products
With push switch input, can be controlled by universal AC push switches
Standard size, can be compatible with existing EU standard frames, and installed into standard size wall box
Radio Frequency: 2.4GHz
Waterproof grade: IP20

The SR-ZG2835KAC-NK2-SW 2-Key Zigbee Push Button Smart Switch is a versatile ZigBee 3.0-based AC switch designed for both neutral and no-neutral wiring setups. It supports resistive, capacitive, and inductive loads with a maximum load of 10A per channel. This smart switch allows for the control on / off of connected light sources and features real-time energy metering to monitor consumption. It can be controlled via ZigBee gateway, ZigBee remote, or local push buttons. Additionally, it supports Touchlink commissioning, self-forming ZigBee networks, and binding with ZigBee Green Power remotes (up to 20 devices). Compatible with universal ZigBee gateways and EU standard frames, it is easy to install and provides reliable wireless control at a 2.4GHz frequency.

Input Voltage	100-240VAC
Output Voltage	100-240VAC
Output Current	10A max
Minimum Load	7W LED(no neutral without bypass), 3W LED(no neutral with bypass), No minimum load requirement with neutral
Max. Number of Parallel Connected Load	9
Size(LxWxH)	86x86x42.4mm
