The Bluetooth to 0-10V Signal MW Sensor Controller features a Bluetooth mesh network that extends control distance by transmitting signals to neighboring devices, allowing for broadcast control of all devices on the 0-10V line via a mobile application. It includes a built-in 20mA 0-10V signal output and supports kinetic energy switches and EnOcean switches EWSSB and EWSDB. In typical indoor environments, the wireless communication range is 20m to 25m, depending on installation conditions. With a standby power consumption of less than 0.5W to meet the latest ERP regulations, it also offers both magnetic reset, activated by touching the top part of the sensor for five seconds, and manual reset options, along with an on-board antenna for improved connectivity.
| Input | Power | 12-24VDC |
|---|---|---|
| Input | Signal | Bluetooth |
| Output,0/1-10V | Current | Max.20mA |
| Control | Dimming Curve | Logarithmic |
| Control | Dimming Method | PWM |
| Environment | Operating Temperature | 0℃~+45℃ |
| Environment | Relative Humidity | 8% to 80% |
| Others | Size | See dimensions |
